| PERFORMANCE |
| Display Size |
23.8" |
| View Area |
526.8x296.3 mm |
| Panel |
In-Plane Switching |
| Backlight |
WLED |
| Aspect Ratio |
16:9 |
| Resolution |
2560x1440 |
| Pixel Pitch |
0.205x0.205 mm |
| Dot / Pixel Per Inch |
123 dpi |
| View Angle (H / V) |
178° / 178° |
| Response Time |
4ms (Extreme mode) / 6ms (Typical mode) |
| Color Support |
16.7 Million |
| Refresh Rate |
60Hz |
| Brightness |
300 cd/m2 |
| Contrast Ratio |
1000:1 |
| Color Gamut |
99% sRGB, 99% BT.709 |
| Screen Surface Treatment |
Anti-glare |
| Curvature |
None |
| Camera |
Modular Camera Support |
| Microphone |
None |
| Speakers |
Modular Speaker Support |
| Power Consumption (Typical / Maximum) |
27W / 161W |
| Power Adapter |
Integrated |
| Touchscreen |
None |
| Smart System |
None |
| DESIGN |
| Stand |
Tilt, Swivel, Pivot, Height Adjust Stand |
| Case Color |
Raven Black |
| Side Bezel Width |
2 mm |
| Mounting |
Supports VESA mount 100mm |
| ThinkCentre M Series Support |
Tiny Support |
| Dimensions (WxDxH) |
- Lowest Position | 539.5 x 199.7 x 348.8mm (21.24 x 7.86 x 13.73 inches)
- Highest Position | 539.5 x 199.7 x 503.8mm (21.24 x 7.86 x 19.83 inches)
- Head Only | 539.5 x 46.5 x 323.7mm (21.24 x 1.83 x 12.74 inches)
|
| Packaging Dimensions (WxDxH) |
620 x 160 x 420 mm (24.41 x 6.30 x 16.54 inches) |
| Weight |
- Monitor With Stand | 5.7 kg (12.6 lbs)
- Monitor Head Only | 3.8 kg (8.4 lbs)
|
| Packaging Weight |
8.6 kg (19.00 lbs) |
| CONNECTIVITY |
| USB Port |
4x USB 3.2 Gen 1 (1x BC 1.2), 1x USB-C® 3.2 Gen 1 (DP 1.4 Alt Mode, up to 100W PD, USB upstream) |
| Video Connector |
1x HDMI® 2.1 TMDS, 1x DP 1.4, 1x DP Out, 1x USB-C® 3.2 Gen 1 (DP 1.4 Alt Mode) |
| Network Connectivity |
1x RJ45, Ethernet (10M/100M/1000M) |
| SERVICE |
| Base Warranty |
3-year |
| CERTIFICATIONS |
| Environmental Certification |
ENERGY STAR® Certified, TCO 9.0, TCO Edge 2.0, EPEAT™ Gold, RoHS |
| Ergonomic Certification |
Eyesafe® Display 2.0, TÜV Low Blue Light (Hardware solution), TÜV Rheinland® Low Blue Light, TÜV Rheinland Flicker Free, TÜV Rheinland Eye Comfort |
| Sync Technology |
None |
| Special Features |
- HDR10 Compliance
- Factory Calibration: Avg. Delta E<2
- Lenovo® ThinkColour (Lenovo Accessories and Display Manager) Support Lenovo ThinkColour supports Windows® 10 & 11, Mac OS, and Windows On Arm (functions vary across systems). Lenovo Accessories and Display Manager is formerly Lenovo Display Control Center.
- Natural Low Blue Light
- Smart Power The Smart Power function intelligently detects overall power consumption and dynamically manages the power delivery to each device
|
| SOFTWARE |
| Operating System |
Support Windows® 10, Windows 11 |
| ACCESSORIES |
| Video Cables |
USB Type-C® to Type-C Cable |
